B-603
Overview
45-Degree Support Knee Brace45-Degree Support Knee Brace
Haydon offers many types of fittings to provide structural connections with H-STRUT® channel. These fittings are available in several materials and finishes to accommodate various applications. H-Strut fittings are designed to be used with 1/2" channel nuts and bolts as standard.
Standard dimensions unless otherwise noted:
- Steel thickness: ¹/₄"
- Width: 1⁵/₈"
- Hole diameter: ⁹/₁₆"
- Hole spacing: 1⁷/₈" on center
- Hole spacing: ¹³/₁₆"from the end
Sizes available:
- B-603-1
- B-603-2
- B-603-3
Download
Product data sheet
Add to Favorites
Specifications
| Model | A | B | Wt.100 Pcs. |
|---|---|---|---|
| B-603-1 | 16-5/8" | 13-5/8" | 232 |
| B-603-2 | 12" | 10-1/8" | 175 |
Material
- Hot Rolled Steel Sheet - ASTM A-1011
- Cold Rolled Steel Sheet - ASTM A-1008
- Stainless Steel-Type 304/316 - ASTM A-240
- Aluminum Fitting - ASTM B-221
Finish
- Electro Galvanized - ASTM B-633
- Hot Dipped Galvanized - ASTM A-123
- Zinc Trivalent Chromium - ASTM B-633-85
- Powder Coated Supr-Green - ASTM B-117
- PVC Coating - Available Upon Request
Technical Information
Additional Lengths and Parts
| Model | A | B | Wt.100/Pcs. |
|---|---|---|---|
| M-611-1 | 2-3/8" | 6" | 110 |
| M-611-2 | 4-3/8" | 8" | 164 |
| M-611-3 | 6-3/8" | 10" | 200 |
| M-611-4 | 8-3/8" | 12" | 253 |
| M-611-5 | 10-3/8" | 14" | 328 |
