RAC
Overview
RACH-STRUT Right Angle Pipe or Conduit Clamps are all manufactured to fit into the standard openings of 1-5/8" channel to support runs of piping where desired, to secure the pipe in place.
- Right Angle Pipe or Conduit Clamps come in Electro-Galvanized (EZN) finish.
- Other finishes available upon request.
- When ordering specify figure number and O.D. size.
Download
Product data sheet
Add to Favorites
Specifications
| Size | A Dia. | B | Wt./100 Pcs. | Std. Pkg. |
|---|---|---|---|---|
| 3/8" | 5/16" | 5/16" | 25 | 50 |
| 1/2" | 5/16" | 1-3/16" | 41 | 50 |
| 3/4" | 5/16" | 1-7/16" | 42 | 50 |
| 1" | 5/16" | 1-11/16" | 47 | 50 |
| 11/4" | 5/16" | 2" | 54 | 50 |
| 11/2" | 5/16" | 2-3/8" | 57 | 50 |
| 2" | 3/8" | 2-3/16" | 85 | 50 |
| 21/2" | 3/8" | 3-3/8" | 106 | 50 |
| 3" | 3/8" | 4-1/8" | 110 | 50 |
| 31/2" | 3/8" | 4-5/8" | 128 | 50 |
| 4" | 3/8" | 4-1/8" | 140 | 50 |
