H-132-OSC

Overview

H-132-OSC strut channels are 3-1/4" X 1-5/8" 12 gauge channels welded channel, back-to-side, with a weight of 3.83 lbs per 100 ft. H-132 strut is the most common, and typically the standard, 12 gauge channel specified for numerous applications. Sometimes known as "deep" strut, it is commonly used for MEP supports, trapeze, seismic bracing, and many other applications. It is available "slotted" or with several other pre-punched hole and weld configurations.

12 Gauge Channel to Welded Back-To-Side
3-1/4" X 1-5/8"
Weight/100 ft. - 3.83 lbs.

Download

Product data sheet

Add to Favorites

Specifications

General

H-STRUT® channels are manufactured from high quality, domestically sourced structural steel and roll formed into shape. These products comply with MFMA-4 standards, and beam and column load tables are calculated in accordance with the ANSI North American Specification for the Design of Cold-Formed Steel Structural Members, 2016 Edition.

Welding

Channel combinations of two or more elements are spot welded together to form various multiple combinations. The spot welds are placed two inches on center throughout the length of the multiple channel sections.

Length Information

H-Strut channels are produced in standard 10' and 20' lengths with a tolerance of ±¹⁄&sub8;". Other lengths are available upon request.

Material

H-Strut channels are produced from prime structural metals covered by the following specifications. (See the technical section for additional information.)

Plain Steel - ASTM A1011 SS Grade 33
Pre-Galvanized Steel - ASTM A653 SS Grade 33, G90
Stainless Steel (Type 304 & 316L) - ASTM A240
Other materials and specifications are available upon request.

Finishes

H-Strut is available in powder-coated and zinc trivalent. Other finishes are available upon request.

Hot-Dip Galvanized - ASTM A123
Zinc Trivalent Chromium (ZTC) - ASTM B633
Powder-Coated
