Name: Four Hole Splice Plate (F-205)
Brand: Haydon

F-205 four hole splice plate for H-STRUT, made from carbon steel with electro galvanized or powder-coated finishes.

F-205 Four Hole Splice Plate for H-STRUT Channels

Four Hole Splice Plate (F-205)

<div class="specifications-wrapper d-flex">

 <div class="single-specification-wrapper single-specification-0">
 <div class="single-specification">
 <div class="illustration">
 <img src="/media/website/illustrations/finishes.svg" alt="material">
 </div>
 <h4 class="font-light">Material</h4>

 <ul><li>Hot Rolled Steel Sheet - ASTM A-1011</li><li>Cold Rolled Steel Sheet - ASTM A-1008</li><li>Stainless Steel-Type 304/316 - ASTM A-240</li><li>Aluminum Fitting - ASTM B-221</li></ul>
 </div>
 </div>

 <div class="single-specification-wrapper single-specification-1">
 <div class="single-specification">
 <div class="illustration">
 <img src="/media/website/illustrations/finishes.svg" alt="finish">
 </div>
 <h4 class="font-light">Finish</h4>

 <ul><li>Electro Galvanized - ASTM B-633</li><li>Hot Dipped Galvanized - ASTM A-123</li><li>Zinc Trivalent Chromium - ASTM B-633-85</li><li>Powder Coated Supr-Green - ASTM B-117</li><li>PVC Coating - Available Upon Request</li></ul>
 </div>
 </div>
</div>
