Electrical Mechanical Tubing (EMT) Clamps (C-1100)
Overview
C-1100H-STRUT Pipe Clamps are all manufactured to fit into the standard openings of 1-5/8" channel to support runs of piping where desired, to secure pipes in place.
- Electrical Mechanical Tubing Clamps come in Electro-Galvanized (EG) finish.
- Other finishes available upon request.
- When ordering specify figure number and O.D. size.
Download
Product data sheet
Add to Favorites
Specifications
| Nom. Comb. Size | O.D. Size | Steel Ga. | Wt./100 Pcs. | Std. Pkg. |
|---|---|---|---|---|
| 3/8" | 0.577 | 16 | 9 | 100 |
| 1/2" | 0.706 | 16 | 11 | 100 |
| 3/4" | 0.922 | 16 | 12 | 100 |
| 1" | 1.163 | 14 | 15 | 100 |
| 1-1/4" | 1.51 | 14 | 18 | 100 |
| 1-1/2" | 1.74 | 12 | 29 | 50 |
| 2" | 2.197 | 12 | 33 | 50 |
Design Loads
Tests performed in accordance with MFMA (Metal Framing Manufacturer’s Association) specifications with a safety factor of 3.0. Loads based on independent laboratory testing.
| Nominal Pipe Size | Slip Thru (lbs) | Slip Along (lbs) | Pullout (lbs) |
|---|---|---|---|
| 1/2" | 213 | 77 | 907 |
| 3/4" | 142 | 169 | 992 |
| 1" | 131 | 174 | 806 |
| 1-1/4" | 354 | 150 | 1,160 |
| 1-1/2" | 335 | 336 | 1,564 |
| 2" | 405 | 506 | 1,572 |
| 2-1/2" | 287 | 548 | 1,610 |
| 3" | 496 | 452 | 1,317 |
| 3-1/2" | 434 | 531 | 1,490 |
| 4" | 518 | 576 | 1,505 |
| 5" | 411 | 564 | 1,313 |
| 6" | 406 | 563 | 1,531 |
| 8" | 580 | 664 | 2,018 |
