B-601

Overview

3-Hole "U" Support

Haydon offers many types of fittings to provide structural connections with H-STRUT® channel. These fittings are available in several materials and finishes to accommodate various applications. H-Strut fittings are designed to be used with 1/2" channel nuts and bolts as standard.

Standard dimensions unless otherwise noted:

• Steel thickness: ¹/₄"
• Width: 1⁵/₈"
• Hole diameter: ⁹/₁₆"
• Hole spacing: 1⁷/₈" on center
• Hole spacing: ¹³/₁₆"from the end

Sizes available:

• B-601: 13/16"
• B-601-1: 1"
• B-601-2: 1-3/8"
• B-601-3: 1-5/8"
• B-601-4: 2-7/16"
• B-601-5: 2-3/4"
• B-601-6: 3-1/4"
• B-601-7: 4-7/8"
